Image: MurmurHash3A Algorithm – High-Level Visual Overview
Published: January 9, 2026 at 9:17:34 PM UTC
Last updated: January 9, 2026 at 9:17:59 PM UTC
Clear, easy-to-understand visualization of the MurmurHash3A hash algorithm, presenting its main conceptual steps such as mixing, scrambling, and finalization in a colorful landscape infographic.
Available versions of this image
The image files available for download below are less compressed and higher resolution - and as a result of that, higher quality - than the images embedded in articles and pages on this website, which are more optimized for file size in order to reduce bandwidth consumption.
Regular size (1,536 x 1,024)
Large size (3,072 x 2,048)
Very large size (4,608 x 3,072)
Extra large size (6,144 x 4,096)
Comically large size (1,048,576 x 699,051)
- Still uploading... ;-)
Image description
The image is a wide, landscape-oriented infographic titled "MurmurHash3A Algorithm" displayed prominently at the top in bold, dark text. Beneath the title, the diagram presents a left-to-right and top-to-bottom flowchart that conceptually explains how the MurmurHash3A hashing process transforms input data into a fixed-size hash output. The style is intentionally high level and abstract, avoiding precise constants or implementation details while still conveying the overall structure of the algorithm.
At the upper left is a rounded rectangular box labeled "Input Data" in a blue color theme. Inside this box, a short line of binary digits is shown, representing arbitrary raw input bits. An arrow leads from this box to the right toward another rounded rectangle in orange labeled "Get 32-bit Key," indicating that the input is first processed in chunks to extract working keys. The arrows are thick and dark, making the data flow easy to follow.
Below the input area, a yellow box labeled "Mix & Rotate" appears, connected by a downward arrow from the input. This box contains simple symbolic icons such as a plus sign, a multiplication symbol, and a curved rotation arrow, suggesting mathematical mixing and bit rotations without committing to exact operations. From this yellow box, a horizontal arrow points to the next orange box labeled "Multiply & Shift." This second orange box includes simplified icons for multiplication and bit shifting, reinforcing that the data is being heavily transformed to spread entropy.
To the right of the "Multiply & Shift" box is a purple box labeled "XOR & Scramble." It is connected by a horizontal arrow, and its interior again shows abstract symbols, including an XOR-like icon and a rotation arrow, communicating the idea of further scrambling and combining the intermediate values. The consistent use of color—yellow for mixing, orange for multiplication and shifting, purple for XOR and scrambling—helps visually group related kinds of operations.
From the "Multiply & Shift" box, a downward arrow leads to a green box labeled "Finalization" with a subtitle "Mix & XOR." This area represents the final avalanche stage of the algorithm, where the internal state is mixed one last time to ensure small input changes produce large output differences. The green color visually separates this final phase from the main body-processing steps above.
At the bottom center of the diagram is a large dark blue rounded rectangle labeled "32-bit Hash Output." Inside it, another string of binary digits is displayed, representing the final hash value produced by the algorithm. A single downward arrow from the green "Finalization" box connects directly into this output block, making it clear that this is the terminal stage of the process.
Overall, the layout is clean, symmetric, and easy to scan, with generous spacing between boxes and consistent arrow styles. The background is white, ensuring strong contrast with the colored elements. The diagram communicates the conceptual pipeline of MurmurHash3A—from raw input, through repeated mixing and scrambling operations, into a final 32-bit hash—without relying on low-level or potentially error-prone specifics, making it suitable for educational or introductory explanations.
The image is related to: MurmurHash3A Hash Code Calculator
