Image: MurmurHash3C Algorithm Overview
Published: January 9, 2026 at 9:10:59 PM UTC
Last updated: January 9, 2026 at 9:11:14 PM UTC
Visual explanation of the MurmurHash3C hash algorithm, illustrating input data, processing loops, finalization stages, and resulting hash output in a clear left-to-right diagram.
Available versions of this image
Image description
The image is a wide, landscape-oriented infographic that visually explains the high-level flow of the MurmurHash3C hashing algorithm in a simplified and technology-neutral way. The background is a smooth dark blue gradient, giving the diagram a modern, technical feel while keeping strong contrast with the foreground elements. At the top center, a large title reads “MurmurHash3C Algorithm,” with the word “Hash” highlighted in a lighter blue tone to emphasize the hashing concept. A subtle curved underline separates the title from the main diagram.
On the far left is a purple rectangular block labeled “INPUT DATA.” Inside it are stylized rows of binary digits such as 01011001, 10110101, and 11010011, followed by an ellipsis to indicate that the data continues. Below this block is a small caption reading “CHUNKED & MIXED,” suggesting that the raw input is first divided into pieces and prepared for processing. A thick white arrow points from this input block toward the center of the diagram.
The middle section is framed by a dashed rectangular outline titled “PROCESSING LOOPS,” with a smaller caption beneath it reading “REPEATED ROUNDS.” Inside this area are three colored square icons arranged horizontally. The first icon is blue and contains abstract crossing tools, representing a generic mixing or multiplication-like operation. The second icon is teal and shows a circular arrow, symbolizing rotation or reordering. The third icon is purple and clearly labeled “XOR,” indicating a bitwise exclusive-or step. White arrows connect these three icons in sequence, showing that the data flows through them repeatedly as part of the algorithm’s core loop.
From the processing area, a large arrow leads to the right side of the image, where a bracketed section titled “FINALIZATION” appears. This section contains three stacked orange-to-red rectangular blocks. The top block is labeled “Final Mix” and is illustrated with small gear icons to suggest a last blending phase. The middle block is labeled “Bit Shift” with a right-pointing arrow symbol, implying bit-level adjustments. The bottom block is labeled “Modulo” and includes a percent sign, representing a final reduction or normalization step. These three blocks are vertically aligned and connected by the overall left-to-right flow.
At the far right is a blue rectangular block labeled “HASH OUTPUT.” Beneath the label is a short hexadecimal-style string, “8F3A12C7,” serving as an example of a final hash value. A white arrow connects the finalization section to this output block, completing the visual pipeline.
Overall, the image avoids low-level technical constants and instead focuses on intuitive symbols, color-coded stages, and directional arrows. The composition clearly communicates that MurmurHash3C transforms binary input data through repeated mixing operations, followed by a finalization phase, to produce a compact hash output.
The image is related to: MurmurHash3C Hash Code Calculator
